MS Channel Raipur Size Chart and Price
As an experienced MS Channel trader, Vishwa Geeta Ispat offers competitive MS Channel prices, transparent pricing, and best working rates for bulk MS Channel orders. With access to multiple steel plants, we ensure price stability, consistent quality, and timely dispatch across India.
Terms and condition
- GST @18% will be charged extra.
- Loading @ Rs 265/- per mt will be charged extra.
- Transit insurance will be charged extra @ 15-25 per ton.
- Transportation costs will be charged extra.
- Dispatch 1-7 working days from receipt of advance.
- Length of the material would be 6-12 meters. Special length also provided.
- Weight tolerance +/- 0.5% is to be allowed.
- Rates are subject to change as per the hourly market situation.
- Products are subject to availability.
Vishwa Geeta Ispat - Live Rate Table
MS Channel Raipur Weight Chart
Accurate MS Channel weight is critical for structural fabrication and construction work, as it directly affects load-bearing performance, material estimation, and overall project costing. A standard MS Channel weight chart helps engineers, contractors, fabricators, and procurement teams verify MS Channel weight per meter, calculate steel quantities precisely, and avoid losses caused by short or underweight MS Channels.
| Item | Diameter in mm | Weight per 12 meter pcs | Approx. pieces in 1 ton (12m each) | Weight (in kg/meter) | Weight (in kg/feet) | Approx. running meter length in 1 ton | |||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MS CHANNEL | 70×35 channel weight | 50 | 19.84 | 4.2 | 1.28 | 238.1 | |||||||||||||||||
| MS CHANNEL | 75×40 channel weight (Light) | 68 | 14.62 | 5.7 | 1.74 | 175.44 | |||||||||||||||||
| MS CHANNEL | 75×40 channel weight (Medium) | 25 | 39.68 | 2.1 | 0.64 | 476.19 | |||||||||||||||||
| MS CHANNEL | 75×40 channel weight (Heavy) | 85 | 11.74 | 7.1 | 2.16 | 140.85 | |||||||||||||||||
| MS CHANNEL | 95×45 channel weight | 72 | 13.89 | 6 | 1.83 | 166.67 | |||||||||||||||||
| MS CHANNEL | 100×50 channel weight (Light) | 70 | 14.37 | 5.8 | 1.77 | 172.41 | |||||||||||||||||
| MS CHANNEL | 100×50 channel weight (Medium) | 95 | 10.55 | 7.9 | 2.41 | 126.58 | |||||||||||||||||
| MS CHANNEL | 100×50 channel weight (Heavy) | 115 | 8.72 | 9.56 | 2.91 | 104.6 | |||||||||||||||||
| MS CHANNEL | 125×65 channel weight | 157 | 6.36 | 13.1 | 3.99 | 76.34 | |||||||||||||||||
| MS CHANNEL | 125×50 channel weight | 120 | 8.33 | 10 | 3.05 | 100 | |||||||||||||||||
| MS CHANNEL | 150×75 channel weight | 202 | 4.96 | 16.8 | 5.12 | 59.52 | |||||||||||||||||
| MS CHANNEL | 175×75 channel weight | 235 | 4.25 | 19.6 | 5.97 | 51.02 | |||||||||||||||||
| MS CHANNEL | 200×75 channel weight | 268 | 3.74 | 22.3 | 6.8 | 44.84 | |||||||||||||||||
| MS CHANNEL | 250×80 channel weight | 410 | 2.44 | 34.2 | 10.42 | 29.24 | |||||||||||||||||
| MS CHANNEL | 250×82 channel weight | 367 | 2.72 | 30.6 | 9.33 | 32.68 | |||||||||||||||||
| MS CHANNEL | 300×90 channel weight | 436 | 2.3 | 36.3 | 11.06 | 27.55 | |||||||||||||||||
| MS CHANNEL | 350×100 channel weight | 512 | 1.95 | 42.7 | 13.01 | 23.42 | |||||||||||||||||
| MS CHANNEL | 400×100 channel weight | 601 | 1.66 | 50.1 | 15.27 | 19.96 |
Specifications and Chemical Composition
MS Channels supplied by Vishwa Geeta Ispat conform to applicable Indian Standards and are suited for Indian construction and fabrication conditions. These quality-controlled MS Channels offer reliable load-bearing strength and dimensional accuracy, along with uniform thickness and structural stability required for industrial structures, sheds, platforms, frames, and infrastructure applications.
| Carbon % | Manganese Max % | Sulphur Max % | Phosphorous Max % | Silicon Max % | Carbon Equivalent |
|---|---|---|---|---|---|
| 0.19 | 0.75 | 0.033 | 0.068 | 0.22 | 0.31 |
| Yield Stress N/mm² | Tensile Strength N/mm² | Elongation % (Min) | Bend Test |
|---|---|---|---|
| 511 | 324 | 33.4 | OK |
| Country Of Origin | Made in Bharat (INDIA) |
| Dispatch Location | Raipur (Chhattisgarh) |
| Material | Mild Steel |
| Test Certification | ISI Test Certificate & Mill TC Available |
| Shape | C Shape |
| Size | 70X35X3.8 mm to 400X100X8.8 mm |
| Minimum Order Quantity (MOQ) | 25 Metric Ton |
| Packaging Details | Bundles |
| HSN Code | 72165000, 72161000, 72163100, 72165000, 72169930, 72163300 |
Frequently Asked Questions
Why Choose Our Products
Accurate MS Channel Weight per Meter
Our MS Channels strictly match standard MS Channel weight per meter (kg/m), helping buyers avoid short-weight issues, site-level discrepancies, and BOQ mismatches. Ideal for those searching MS Channel weight chart and accurate MS Channel weight.
Consistent Quality from Reputed Steel Plants
We supply MS Channels sourced directly from trusted Indian steel manufacturers, ensuring uniform thickness, straightness, and reliable load-bearing strength. Preferred by buyers looking for the best quality MS Channel supplier in India.
Wide Range of Standard MS Channel Sizes
Available in multiple ISMC sizes and weights, suitable for fabrication, industrial sheds, platforms, frames, and structural applications. Common searches covered: MS Channel sizes, ISMC channel size chart, C channel India.
Competitive MS Channel Prices & Bulk Rates
Our strong plant network enables us to offer competitive MS Channel price today, best working rates, and dependable bulk MS Channel supply for large projects across India.
Reliable Delivery & PAN India Supply
Known for timely dispatch and dependable delivery timelines, we support projects that demand consistency. A trusted choice for buyers searching MS Channel supplier PAN India and MS Channel trader India.
Trusted Steel Trader with Long-Term Credibility
Backed by decades of experience in steel trading, Vishwa Geeta Ispat is trusted by builders, contractors, fabricators, and infrastructure developers for transparent pricing, professional coordination, and long-term reliability.
MS Channels Applications
- Structural Frames and Beams
- Industrial Sheds and Warehouses
- Fabrication and Support Structures
- Infrastructure and Utility Structures
- Transmission, Towers, and Heavy Frameworks
Our Promises
- Assured Quality and ISI Compliance
- Accurate Weight and Genuine Material
- Competitive Pricing and Transparency
- Timely PAN India Delivery
- Trusted Partnership and Support.
