Hot-Rolled
H Beam
ISHB Sections
Wide-flange H Beam sections for industrial columns, multi-storey structures, warehouses, gantries, and heavy fabrication where axial load capacity, flange stability, and dimensional accuracy are non-negotiable.
H Beam ISHB — Up Close
Wide-flange H Beam sections with deeper flange stability, column-grade structural geometry, and mill-standard finish for heavy-duty applications.
01
02
0304What Is an
H Beam?
An H Beam — also designated ISHB (Indian Standard Heavy Beam) or Wide Flange Beam — is a hot-rolled structural steel section with an H-shaped cross-section. It consists of two wide flanges connected by a central web, with the flange width approximately equal to or close to the section depth. This near-square profile is what fundamentally separates H Beam from I Beam and makes it the preferred choice for column applications.
In the ISHB designation system, the number refers to the nominal depth in millimetres — so ISHB 300 is 300mm deep with flanges of approximately 300mm width. This near-equal proportion of depth and flange gives H Beams exceptional resistance to both axial compression and lateral buckling, the two dominant forces acting on structural columns.
H Beams are produced under IS:808 dimensional standards and typically conform to IS:2062 Grade A material specification. Primary mill supply from SAIL and RINL comes with full traceability through mill test certificates. H Beams can be welded, drilled, bolted, and flame-cut using standard fabrication equipment — and unlike concrete columns, they support longer clear spans with fewer intermediate supports, enabling open-plan industrial and commercial layouts.
H Beams are also manufactured in European (HEA/HEB/HEM) and American (W-section) standards. If your structural drawing specifies a section in those formats, confirm the equivalent ISHB size and weight with your structural engineer before ordering.
H Beam vs I Beam — Key Differences
The right section depends on how your structure loads it. Use this guide to specify correctly from the start — the wrong choice can compromise design efficiency and add unnecessary project cost.
Applications
- Wider flanges — near-equal depth and width allows better load distribution across both axes simultaneously
- Higher axial capacity — thicker section mass makes H Beam the default choice for columns carrying vertical compression
- Greater torsional resistance — wide flanges resist twisting under eccentric loads and lateral wind forces on columns
- Better for long-term durability — heavier cross-section suits large-scale projects where structural life and load headroom matter
- Open space design — steel columns need fewer intermediate supports than concrete, enabling wider spans and open-plan layouts
Applications
- Narrow flanges — web depth significantly greater than flange width concentrates material where bending stress is highest
- Higher bending efficiency — deeper web relative to flange gives superior moment of inertia for horizontal span loading
- Lighter sections available — ISMB starts at 8.9 kg/m vs ISHB minimum at around 23 kg/m, making I Beam more economical for lintels and light frames
- More economical for lightly loaded beams — for spans where axial compression is not the dominant force, I Beam delivers adequate performance at lower cost
- Standard for rafters and purlins — horizontal roof members and crane girder beams use ISMB as the default section
| Parameter | H Beam (ISHB) | I Beam (ISMB) |
|---|---|---|
| Cross-section shape | H-shape — flanges ≈ depth | I-shape — depth > flange width |
| Primary loading direction | Axial (compression) + bending | Bending (horizontal spans) |
| Best structural role | Columns, gantry legs, heavy portals | Beams, rafters, lintels, mezzanine |
| Flange width vs depth | Approximately equal | Flange much narrower than depth |
| Torsional stiffness | High — suitable for columns | Lower — not ideal for column use |
| Weight range (IS:808) | 23–302 kg/m | 8.9–123 kg/m |
| HSN Code | 7216 | 7216 |
| Standard | IS:808 / IS:2062 | IS:808 / IS:2062 |
H Beam Weight Calculator
Select ISHB section, quantity, and length to get instant H Beam weight in kg and truck planning for your project.
Stocked for Column Structures & Heavy Projects
Primary mill H Beam and commercial grade wide-flange supply backed by weight verification, source transparency, and mill test certificates.
Two Supply Tiers.
Choose by Specification, Not Guesswork.
Primary grade where test certificates and strict mill sourcing matter. Commercial grade where cost efficiency matters without compromising dimensional reliability.
Vizag Steel
- Multi-storey building columns and heavy structures
- Industrial warehouses and crane-support frames
- Bridge piers, heavy portals, and infrastructure
- Projects where mill test certificate is mandatory
- Consultant-specified branded wide-flange sections
Rolling Mills
- Industrial shed columns and heavy platforms
- General structural work without MTC requirement
- Agricultural and warehouse support frames
- Budget-sensitive heavy fabrication
- Projects where section consistency matters more than brand
H Beam Size Chart & Weight Chart in kg
Standard ISHB section sizes per IS:808 — H Beam weight per metre and per foot for accurate BOQ estimation and column load planning.
| Section | Depth × Flange (mm) | Flange Thk | Web Thk | kg/m | kg/ft | Use |
|---|---|---|---|---|---|---|
| ISHB 150 | 150 × 150 | 9.0 mm | 5.4–8.4 mm | 27.1–34.6 | 8.3–10.5 | Light structural columns |
| ISHB 150 (HB-152×152) | 152 × 152 | 11.9 mm | 7.9 mm | 37.1 | 11.3 | Medium columns |
| ISHB 200 | 200 × 200 | 9.0 mm | 7.8 mm | 40.0–49.1 | 12.2–15.0 | Industrial supports |
| ISHB 250 | 250 × 250 | — | — | 71.8 | 21.9 | Column grids |
| ISHB 300 | 300 × 300 | — | — | 94.5 | 28.8 | Heavy shed columns |
| Section | Depth × Flange (mm) | Flange Thk | Web Thk | kg/m | kg/ft | Use |
|---|---|---|---|---|---|---|
| ISHB 350 | 350 × 250 | — | — | 137.0 | 41.8 | Heavy framing, portals |
| ISHB 400 | 400 × 300 | — | — | 172.0 | 52.4 | Industrial sheds |
| ISHB 450 | 450 × 300 | — | — | 204.0 | 62.2 | Warehouse columns |
| ISHB 500 | 500 × 300 | — | — | 238.0 | 72.5 | Heavy structures |
| Section | Depth × Flange (mm) | Flange Thk | Web Thk | kg/m | kg/ft | Grade | Use |
|---|---|---|---|---|---|---|---|
| ISHB 600 | 600 × 300 | — | — | 302.0 | 92.1 | Primary | Bridge piers / major spans |
| HB 203×203 | 203 × 203 | 13.0 mm | 8.9 mm | 52.0 | 15.9 | Primary | Building columns |
| HB 203×152 | 203 × 152 | 16.5 mm | 8.9 mm | 52.0 | 15.9 | Primary | Mixed-load columns |
| HB 116×100 | 116 × 100 | 10.0 mm | 8.5 mm | 23.0 | 7.0 | Commercial | Light industrial columns |
HB sections (203×203, 203×152, 116×100) sourced from Mahamaya Steel Industries, Raipur · IS:808 dimensional standard · ±2.5% weight tolerance
Standard lengths: 6 metres and 12 metres · Weights per IS:808 · Actual may vary within rolling tolerances · Mill TC available for primary grade
Rolling Tolerances & Chemical Composition
Permissible deviations for ISHB sections and IS:2062 chemical limits for Grade A material.
| Parameter | Tolerance |
|---|---|
| Depth — up to 200mm | ± 2.0 mm |
| Depth — 200 to 400mm | ± 3.0 mm |
| Depth — above 400mm | ± 4.0 mm |
| Flange width — up to 150mm | ± 2.0 mm |
| Flange width — above 150mm | ± 3.0 mm |
| Sectional weight | ± 2.5% |
| Fixed length supply | + 100 mm |
| Camber (straightness) | 0.1% of length |
| Web thickness | ± 0.5 mm (up to 6mm) / ± 1.0 mm (above) |
| Element | Max. % (Grade A) |
|---|---|
| Carbon (C) | 0.23 |
| Manganese (Mn) | 1.50 |
| Sulphur (S) | 0.050 |
| Phosphorus (P) | 0.050 |
| Silicon (Si) | 0.40 |
| Carbon Equivalent (CE) | 0.42 |
| Yield Strength Min. | 250 N/mm² |
| Tensile Strength | 410–540 N/mm² |
| Elongation Min. | 23% |
Why Structural Buyers in Central India Buy H Beam from Us
Not just supply. Controlled sourcing, weight verification, and practical support for buyers who need to get the job done right.
What Gets Built with H Beam
FAQ — H Beam Size Chart, Weight & Price
Need a
Bulk
H Beam Quote?
Share your BOQ or ISHB size list and we'll help you estimate the right sections, source grade, quantity, and dispatch plan for your project.
- Share BOQ or H Beam size list on WhatsApp
- Primary or commercial grade recommendation
- H Beam weight & dispatch planning support
- Mill TC available for SAIL / RINL primary supply
