Indian Standard
MS Channel
ISMC Sections
Hot-rolled mild steel C-channels (ISMC) conforming to IS:2062 for industrial frames, roof purlins, cable tray supports, mezzanine flooring, conveyor structures, and column stiffeners where consistent web depth and flange width are critical to fabrication accuracy.
MS ISMC Channel — Up Close
Hot-rolled C-channels with consistent web height, flange width, and IS:2062 dimensional compliance for industrial structural and fabrication applications.
01
02
03
04What Is an
MS Channel?
A mild steel channel, commonly known as an MS Channel, MS C-Channel, or MS U-Channel, is a hot-rolled structural steel section with a C-shaped or U-shaped cross-section — a vertical web with two horizontal flanges extending on the same side. The ISMC (Indian Standard Medium Weight Channel) designation refers specifically to channels rolled to IS:808 dimensional standards with material conforming to IS:2062.
MS Channels have a tapered inner flange face — unlike European parallel flange channels (PFC) — which affects how they connect with gusset plates and welded connections. This is important to note when combining with imported or fabricated sections on mixed-standard projects.
The moderate carbon content (C max 0.20%) makes MS Channel readily weldable, drillable, and cuttable with standard fabrication equipment, without requiring special preheat for most thicknesses. This versatility makes ISMC the default structural section for industrial shed frames, roof purlins, mezzanine floors, cable trays, and conveyor supports across manufacturing and infrastructure projects.
HSN Code: 7216 — Angles, shapes and sections of iron or non-alloy steel, hot-rolled, hot-drawn or extruded.
MS Channel Weight Calculator
Select ISMC section size, quantity, and length to instantly calculate MS Channel weight per metre, total tonnage, and estimated truck requirement.
Stocked for Fabricators, Contractors & Industrial Project Teams
IS:2062 ISMC channels backed by section verification, weight confirmation, and mill test certificates on primary branded supply.
Two IS:2062 Grades.
Specify by Load Requirement, Not by Habit.
IS:2062 Grade A and Grade B differ in tensile strength and yield point. For structural frames carrying calculated design loads, Grade B is the safer specification. Grade A suits general fabrication where load calculations are informal.
Structural Channel
- Industrial shed columns, rafters, and crane beam supports
- Conveyor structures and elevated walkway frames
- Mezzanine floor beams and staircase stringers
- Cable tray brackets and electrical panel supports
- Projects where structural drawings specify IS:2062 grade
Fabrication Channel
- Light framing, shelving, and rack structures
- Gate frames, compound boundary supports
- Agricultural machinery frames and storage racks
- General workshop fabrication and furniture bases
- Projects where grade TC is not mandated by specification
MS Channel Size Chart & Weight Chart
ISMC standard dimensions and MS Channel weight per metre as per IS:808 / IS:2062. Use for BOQ estimation, load planning, and procurement verification.
| Title | Section | Depth (mm) | Flange (mm) | Web Thk (mm) | Flange Thk (mm) | kg/m | kg/ft | Use |
|---|---|---|---|---|---|---|---|---|
| MS Channel | ISMC 75 | 75 | 40 | 4.4 | 7.3 | 6.80 | 2.07 | Light frames, racks |
| MS Channel | ISMC 100 | 100 | 50 | 5.0 | 7.5 | 9.56 | 2.91 | Purlins, supports |
| MS Channel | ISMC 125 | 125 | 65 | 5.3 | 8.1 | 13.10 | 3.99 | Cable trays, brackets |
| MS Channel | ISMC 150 | 150 | 75 | 5.7 | 9.0 | 16.40 | 5.00 | Roof purlins, frames |
| MS Channel | ISMC 175 | 175 | 75 | 6.0 | 10.2 | 19.60 | 5.97 | Industrial frames |
| MS Channel | ISMC 200 | 200 | 75 | 6.2 | 11.4 | 22.10 | 6.74 | Mezzanines, conveyors |
| MS Channel | ISMC 225 | 225 | 80 | 6.5 | 12.4 | 26.10 | 7.96 | Staircase stringers |
| MS Channel | ISMC 250 | 250 | 82 | 7.1 | 12.5 | 30.40 | 9.27 | Heavy supports, beams |
| MS Channel | ISMC 300 | 300 | 90 | 7.8 | 13.6 | 36.30 | 11.07 | Crane runway beams |
| MS Channel | ISMC 350 | 350 | 100 | 8.1 | 13.5 | 42.70 | 13.02 | Heavy industrial frames |
| MS Channel | ISMC 400 | 400 | 100 | 8.8 | 15.3 | 49.40 | 15.06 | Structural columns |
Weights as per IS:808 / IS:2062 standard · Standard lengths: 12 metres · Mill TC available on request · Actual dimensions and weight may vary within IS tolerance
Rolling Tolerances & Chemical Composition
Permissible deviations for ISMC sections and IS:2062 chemical limits for Grade A (E250).
| Parameter | Tolerance |
|---|---|
| Depth — up to 100mm | ± 2.5 mm |
| Depth — 100 to 200mm | ± 3.0 mm |
| Depth — above 200mm | ± 3.5 mm |
| Flange width — up to 100mm | ± 2.0 mm |
| Flange width — above 100mm | ± 3.0 mm |
| Sectional weight — up to 100mm depth | ± 2.5% |
| Sectional weight — above 100mm depth | +3.5% / −2.5% |
| Fixed length supply | + 100 mm |
| Straightness | 0.1% of length |
| Element | Max. % (E250 / Grade A) |
|---|---|
| Carbon (C) | 0.20 |
| Manganese (Mn) | 1.50 |
| Sulphur (S) | 0.040 |
| Phosphorus (P) | 0.040 |
| Silicon (Si) | 0.40 |
| Carbon Equivalent (CE) | 0.42 |
| Yield Strength Min. | 250 N/mm² |
| Tensile Strength | 410–540 N/mm² |
| Elongation Min. | 23% |
Why Fabricators & Industrial Buyers in Central India Source MS Channel from Us
Section depth matters in channel procurement. An ISMC 150 labelled as ISMC 175 creates fit-up errors, weld rework, and structural non-compliance on site.
What Gets Built with MS ISMC Channel
FAQ — MS Channel Size Chart, Weight & Price
Need a
Bulk
Channel Quote?
Share your BOQ or ISMC section list and we'll help you estimate the right grade, quantity, and dispatch plan — with section verification built in.
- Share ISMC sizes, grade, and quantity on WhatsApp
- IS:2062 Grade A or Grade B guidance included
- MS Channel weight and dispatch planning support
- Mill TC available for branded primary supply
