MS Round Bar Price Today, Weight Chart & Size Chart | Mild Steel Round Bar Supplier Raipur
MS Round Bar Supplier · IS:2062 Grade A & B · Raipur, Chhattisgarh

Hot-Rolled
MS Round
Solid Bars

Mild steel solid round bars in IS:2062 Grade A and Grade B, available from 6mm to 100mm diameter. Widely used for shafts, axles, pins, dowels, forging stock, reinforcement inserts, grill work, and general workshop fabrication — where circular cross-section geometry and reliable material chemistry are non-negotiable.

IS:2062 Compliant Grade A & Grade B 6mm to 100mm Mill TC Available Weighed Dispatch
Enquire Now →

MS Round Bar Weight Calculator

Select diameter, quantity, and length to instantly calculate MS Round bar weight per metre, total tonnage, and truck requirement for your project.

Round Bar Weight per Metre
kg / metre
Total Weight
metric tons
Truck Required
Formula: (π/4) × Dia(mm)² × 0.00000785 kg/mm · Weights are theoretical. Actual weight may vary within IS:2062 rolling tolerances.

Stocked for Fabricators, Machinists & Industrial Buyers

IS:2062 Grade A and Grade B MS Round bars backed by diameter verification, weight-checked dispatch, and mill test certificates on primary supply.

Two Grades.
Pick the Right One Before You Cut.

IS:2062 Grade A and Grade B round bars look identical on a rack. The difference is chemistry — and that chemistry determines how the bar behaves when welded, turned, forged, or loaded in service.

Grade B — Precision & Structural Use
Primary Grade
IS:2062 Grade B
SAIL · Jindal Steel · Vizag Steel · RINL
Best for
  • Shafts, axles, and rotating machine components
  • Forging stock and heat-treatment blanks
  • Turned, drilled, and threaded precision parts
  • Welded structural assemblies and load-bearing frames
  • Projects requiring mill TC and grade documentation
"Specify Grade B whenever the bar will be machined, welded under load, or forged — tighter carbon and sulphur limits ensure dimensional stability and weld integrity."
Grade A — General Fabrication
Grade A &
Commercial Grade
Dimensional accuracy · Value-focused procurement
Best for
  • Gate bars, grills, and railing pickets
  • Anchor pins, dowels, and concrete inserts
  • Light workshop fabrication and general joinery
  • Agricultural equipment axles and simple hinge pins
  • Projects where TC is not mandated by specification
"We verify diameter and weight against IS:2062 before every dispatch — no under-size bars shipped as full-diameter stock."

MS Round Bar Size Chart & Weight Chart

IS:2062 standard MS Round bar weight per metre. Use for BOQ estimation, purchase verification, and load planning.

Small Diameter Rounds Grills · Pins · Dowels · Wire Work
Title Dia (mm) Area (cm²) Wt per Metre (kg/m) Wt per 12M (kg) Typical Use
MS Round60.280.2222.67Stirrups, links
MS Round80.500.3954.74Grills, ties
MS Round100.790.6177.40Gate pickets, pins
MS Round121.130.88810.66Hinges, dowels
MS Round162.011.57818.94Anchor bolts, rods
MS Round203.142.46629.59Light shafts, spindles
MS Round223.802.98435.81Pins, pivot rods
MS Round254.913.85346.24General fabrication
Medium & Large Diameter Rounds Shafts · Forging · Structural
Title Dia (mm) Area (cm²) Wt per Metre (kg/m) Wt per 12M (kg) Typical Use
MS Round286.164.83458.01Shafts, couplings
MS Round328.046.31375.76Axles, forging stock
MS Round3610.187.99095.88Machinery parts
MS Round4012.579.865118.38Heavy shafts, rolls
MS Round4515.9012.490149.88Industrial spindles
MS Round5019.6315.413184.96Press pins, forging
MS Round6028.2722.195266.34Drive shafts
MS Round7544.1834.681416.17Heavy industrial
MS Round10078.5461.654739.85Large forging, bases

Theoretical weight: (π/4) × Dia(mm)² × 0.00785 kg/cm³ · IS:2062 Grade A & B · Stock lengths: 6M and 12M · Actual weights vary within rolling tolerance

Why Machinists & Industrial Buyers in Central India Buy MS Round from Us

Not just supply. Diameter-verified stock, weight-checked dispatch, and practical guidance for buyers who can't afford an off-spec bar on a precision turning or forging job.

🔵
Diameter Verified
Under-size round bars — sold as 25mm but measuring 23.5mm — are a common issue in commercial supply. We verify diameter with callipers against IS:2062 tolerance before every dispatch. No surprises at the lathe.
📋
Mill TC on Primary Supply
For IS:2062 Grade A and Grade B material from SAIL, Jindal, and Vizag Steel, mill test certificates covering chemical composition and tensile results are available for compliance-driven projects.
⚖️
Weight-Checked Dispatch
Every consignment is weighed before dispatch. You receive what the invoice says — critical when your project BOQ is built on a specific weight budget and short supply wastes time and cost.
✂️
Cut-to-Length Available
Standard 6M and 12M lengths are stock. Project-specific cutting is available for qualifying quantities — reduces offcut waste on shaft blanks, pin components, and precision fabrication jobs with fixed piece lengths.
🏭
Full Structural BOQ Supply
Need MS Round, Flats, Angles, Channels, and TMT on one job? We consolidate multi-product orders on a single bill and dispatch — fewer vendors, cleaner site and workshop coordination.
🔍
Source Transparency
For commercial grade bars, we disclose brand and source details on request before dispatch — stopping buyers from receiving mis-labelled bars passed off as IS:2062 primary when the application demands traceable material.

What Gets Made with MS Round Bar

⚙️

Shafts & Axles

Grade B IS:2062
20mm to 100mm
🔩

Pins & Dowels

Grade A / Grade B
6mm to 32mm
🔨

Forging Stock

Grade B IS:2062
32mm to 100mm
🪟

Gate & Window Grills

Grade A IS:2062
8mm to 20mm
🏗️

Concrete Anchor Inserts

Grade A / Grade B
12mm to 32mm
🛠️

Turned & Threaded Parts

Grade B IS:2062
16mm to 75mm
🌾

Agricultural Equipment

Grade A / Grade B
16mm to 50mm
🏭

Industrial Machinery

Grade B IS:2062
40mm to 100mm

FAQ — MS Round Bar Size Chart, Weight & Price

What is the difference between MS Round Bar and TMT Bar?
Both are circular mild steel bars, but they serve fundamentally different purposes. MS Round Bar (IS:2062) is a solid, hot-rolled bar intended for fabrication, machining, forging, and general structural use — not for embedding in concrete as reinforcement. TMT Bar (IS:1786) has a ribbed surface and a thermomechanically treated core that gives it the high yield strength required for RCC construction. Using MS round bars as slab or column reinforcement instead of TMT is a specification violation and a structural risk.
How is MS Round bar weight per metre calculated?
The standard formula is: (π/4) × Dia(mm)² × 0.00000785 kg/mm. Simplified: Dia(mm)² × 0.006165 kg/m. For a 25mm round bar: 25² × 0.006165 = 3.853 kg per metre. A 12-metre bar weighs approximately 46.24 kg. Use our weight calculator above to get total tonnage for any diameter, quantity, and length combination.
What is the difference between IS:2062 Grade A and Grade B for round bars?
Both grades are weldable mild steel, but Grade B has a lower maximum carbon content (0.20% vs 0.23%) and tighter sulphur and phosphorus limits. This gives Grade B predictably better weldability, improved machinability consistency, and more reliable behaviour under heat treatment or forging. For gate grills, dowels, and non-critical pins, Grade A is adequate. For shafts, axles, turned components, and welded load-bearing assemblies, always specify Grade B.
Can MS Round bars be turned, threaded, and machined?
Yes. IS:2062 mild steel round bars are fully machinable using standard HSS and carbide tooling. They can be turned on a lathe, centre-drilled, threaded, knurled, and case-hardened. For precision diameter work — tight shaft tolerances, splined outputs, or journal bearing seats — the hot-rolled scale should be machined off first. For applications requiring very tight tolerances from the start, cold-drawn bright bars are a better starting material than hot-rolled MS round.
What is the standard supply length for MS Round bars?
MS Round bars are typically stocked in 6 metre and 12 metre random lengths. Smaller diameters (6mm to 20mm) are commonly available in 6M lengths. Medium and larger diameters (25mm and above) are standard mill output in 12M lengths. Cut-to-length supply is available for qualifying project quantities — useful for shaft blanks, pin batches, and component manufacturing where a defined piece length reduces turning waste.
How does MS Round Bar price change and what drives it?
MS Round bar price is driven by billet and bloom input costs at the mill, rolling demand cycles, freight, and broader HRC and long-product market conditions. Prices can shift weekly around mill revision cycles and seasonal construction peaks. We provide same-day rates via WhatsApp — always get a current quote before placing a purchase order, especially for volumes above one tonne.
What is the difference between MS Round Bar and Bright Bar?
MS Round Bar (hot-rolled) has a rough, oxidised surface from rolling and dimensional tolerances of ±0.5mm or more. Bright Bar (cold-drawn) is produced by drawing hot-rolled rod through a die, which gives a smooth, clean surface, tighter dimensional tolerances (±0.1mm or better), improved straightness, and slightly higher yield strength from cold-working. Bright bar costs more but saves machining time when tolerance and surface finish matter from the start.

Need a
Bulk
Round Bar Quote?

Share your diameter list and quantities and we'll turn around a rate with diameter verification and dispatch plan included.

500+
Projects supplied
2 hrs
Rate turnaround
100%
Diameter-verified dispatch
Chat for Bulk MS Round Order
Fast estimate · Diameter & grade guidance
  • Share diameters, grade, and quantity on WhatsApp
  • IS:2062 Grade A or Grade B guidance included
  • MS Round weight and dispatch planning support
  • Mill TC available for branded primary supply
Chat on WhatsApp 📞 Call +91 92000 49000
Available Mon–Sat · 9 AM to 6 PM IST
